Safelok I Clipper & De-Clipper
The FP-171 Safelok Clipper is designed to remove and install Safelok I fasteners that are used to retain the rail to sleepers. The FP-171 can be used on rail sizes from 41kg/m to 68kg/m using traditional concrete sleepers.
The workhead removes and installs Safelok I clips using hydraulic force rather than operator exertion. This significantly improves efficiency and eliminates manual handling hazards associated with installing and removing Safelok clips.
By using the FP-171, injuries from traditional methods of removing these clips (Hand Tools) have been eliminated.
[1] When shoulder-shoulder centres change (i.e. sleepers differ between rail sizes) a spanner is required to adjust width.
Features
- Simple Tool-free set up on track [1]
- Clip drive adjustment, preventing over/under drive
- Simple push/pull knob change between Clipping and Unclipping
- Work light
- Ergonomic, height adjustable handles
- Precisely balanced – only 3-5 kg on operator
- Designated lift point for mechanical lifting
- Back Strain
- Repetitive Strain Injury
- Hammer Strikes to Legs
- Damage to Feet Through Striking/or Clips Hitting Ball of Foot
- Struck by Flying Clips
- Infrastructure Damage
- Flow (L/min): 30
- Pressure (psi) max: 2,680
- Weight (kg) wet: 145
- Length (mm): 1200
- Width (mm): 900
- Height (mm): 700
Model code — quote this in your enquiry
FP-171Downloads
